600 polar Park
Power and Performance in the Park
Representative of a new generation. Pioneer and milestone. Dream machine. This is what can happen when a manufacturer develops a snow groomer in close cooperation with its customers. With the PistenBully 600 Polar Park, we have jointly succeeded in setting new standards. In terms of power and performance. In efficiency, operation and comfort. The new PistenBully 600 Polar Park is lighter than any other in its class. And more environmentally friendly.
The PistenBully 600 Polar Park is more than a normal snow groomer. It is the park professional – ready for all disciplines. Developed together with the best riders and shapers in the world. Equipped with everything you could wish for when creating terrain parks.
Joystick for intuitive control with just one hand. Clear iTerminal with simple operation. Driver's seat, joystick and armrest as ergonomic operating unit.
Thanks to the maximum flexibility of the front and rear attachments, there are hardly any limits to the design of the park.
It was the first to meet the requirements of EU emission stage V. With diesel particulate filter. For reduced exhaust emissions and low fuel consumption. Compact and easy to maintain.
The park specialist – The PistenBully 600 Polar in the Park model variant.
Developed together with the best riders and shapers in the world.
Equipped with everything you need for terrain park grooming.
Flexible ParkBlade for extremely precise shaping and perfect results. Offers more scope for creative work. And enables even more unusual shapes. Backblading teeth leave the perfect structure when grading a landing in reverse.
Fitted as standard in the ParkBlade for easy transport of rails, funboxes and other park accessories. As a one-man show. Ideal for competitions.
Optimum kinematics. For high mobility and more flexibility.. Together with the AlpineFlexTiller it facilitates an impressive working range of 162⁰. Perfect for shaping and reshaping kickers and ramps, jumps and pipes.
Faster response, direct proportional control of all functions.
With ParkPro kinematics and reinforced cylinders. No intermediate frame necessary.
Control of the rear carrier via joystick for intuitive operation. Position the tiller precisely and smoothly as you work.
As flexible as a Swiss army knife, our undercarriage in combination with the chain can be adapted to all customer requirements and thus offers the perfect solution for every area of application, regardless of what is important: pushing, climbing ability, turning ability, transport or heavy additional equipment.
Almost 200 degrees of movement of the tiller leaves nothing to be desired in park construction. Thanks to direct operation via the joystick, every contour can be worked in detail and the result is unique, just like when preparing with SlopeTracer and AutoTracer.
The Park Quick Coupler System offers modified kinematics for even larger movement radii during park construction. Thanks to the improved hydraulics, all parking requirements can be mastered precisely, quickly and powerfully.
Utility of use speaks for our ParkBlade. Integrated hydraulic transport tines are the perfect solution when moving park equipment. The wide side wings, together with the vertical cutting edges enable sharply cut side walls and working widths of up to 5.7 m.
The driver is the center of attention. This guiding principle is realized in our cab with comfort, ergonomics and intuitive operation. Thanks to generous window glass, perfect arrangement and ideal LED illumination, visibility is exceptional, especially at night.
For a steady hand and safe handling in every driving situation: driver's seat, armrest and joystick are firmly connected. An ergonomic and comfortable unit. Individually adjustable to the driver. Enables fatigue-free operation, even when driving in rough cut park features.
Ergonomic and freely movable in all directions. For intuitive control. The four axes of the joystick allow four simultaneous movements of the blade. And proportional control of the attachments. All with just one hand.
High-quality and easy-care interior trim. New floor assembly. Both with innovative thermal insulation and significantly improved soundproofing, making the PistenBully 600 Polar Park quieter than ever before. The optimized ventilation in the center console ensures a perfect interior climate - with comfort automatic climate control for the first time on request, plus plenty of space and freedom of movement.
10-inch display with touch control. Clear and user-friendly. All active vehicle systems are highlighted in color. With quick navigation option via symbols. Completely prepared for SNOWsat.
Precise steering: The semi-steering wheel is infinitely adjustable side-to-side and fits comfortably in the hand. The driver effortlessly steers the PistenBully and finds the most important functions directly in the steering.
As an option to the steering wheel: Stick control for direct handling and steering. A thumb dial potentiometer regulates travel speed.
Despite lower fuel consumption, significantly more power and torque than its predecessor. Long range due to larger tank volume (300 l) for efficient and economical operation.
Compact engine with simple design. Less complex components and improved access. Thus clear, easy to maintain and less prone to malfunctions and errors.
Environmentally friendly pioneer: With the clean 6-cylinder engine with 520 hp including diesel particulate filter, the PistenBully 600 Polar Park was the first snow groomer in the world to comply with EU Stage V.
Rear implement carrier with intelligent, active steering assistance. Possible in rigid position (fixed) as well as in floating position (relieved). When activated the tiller follows the PistenBully in the same curve radius. Automatic counter-steering on side slopes. For automatic support and relief of the driver!
Intelligent control of the combined implement carrier. Can be used like a parallel tool carrier via software. Ensures perfect ground adaptation of the tiller in undulating terrain and automatically adjusts the tilling depth. The patented SlopeTracer simplifies operation and enables very large movement radii.
|Type||Cummins X 12|
|Number of cylinders||6|
|Displacement||11,8 l / 11.800 cm³|
|Performance according to ECE||382 kW / 520 PS|
|Max. torque||2.375 Nm @ 1.200 U/min|
|Tank capacity||300 l|
|Fuel consumption||from 19,5 l/h|
|Tank capacity DEF (AdBlue)||38 l|
|Emission standard||EU Stage V and EPA Tier 4F (USA)|
|Traction drive pump||175 cm³|
|Traction drives||125 cm³|
|Milling drive||105 cm³|
|Type||Cummins X 12|
|Number of cylinders||6|
|Displacement||11.8 l / 11,800 cc|
|Performance according to ECE||512 hp|
|Max. torque||2,250 Nm @ 1,200 rpm|
|Tank capacity||79 gal|
|Fuel consumption||from 5.15 gal/h|
|Tank capacity DEF (AdBlue)||10 gal|
|Emission standard||EU Stage V and EPA Tier 4F (USA)|
|Traction drive pump||175 cc|
|Traction drives||125 cc|
|Milling drive||105 cc|
Gearbox, Chassis & Wheels
- Optimized transfer case with less noise and vibration
- Exclusively trailed axles for improved driving behavior
- Shorter axles for better accessibility to the drive components
- Reinforced rocker arm and wheel bearing due to larger taper roller bearings
- QuickAdjust for quick adjustment of the chassis via gear mechanism
- Individual axle loads and spring characteristics for improved ride comfort (solo/winch)
- More running smoothness and low pitching behavior due to damping of composite bushings
- Magnum sprocket
- Solid tires
- Snow fenders to prevent snow spray
Hydraulics and working hydraulics
- Electro-hydraulic brake
- New transfer case tilts the drive pumps outwards by 5°.
- Optimized accessibility
- 20% higher flow output than the predecessor
- Optimized control for better efficiency
- High pressure filter
- Calibrated valves with identical response in all vehicles
- Best performance values for speed and responsiveness
- Individually adjustable valve characteristics
- All functions can be controlled proportionally and independently of each other
- Common parts (e.g. proportional valves and solenoid coils)
- High-end sound system precisely tuned to the vehicle
- Rear camera color
- DAB+ radio
- Bluetooth hands-free kit
- Connections: USB and audio-in
- Park comfort driver's seat with swivel function
- LED light package
- LED SideFinder lights integrated in the support frame
- LED TillerFlap luminaires
- LED BladeFlap luminaires
- Additional LED indicators and tail lights integrated in the support frame
Electronics and batteries
- Simple onboard diagnostics with error codes in plain text
- Automatic temperature compensation with cold run protection of the components
- Maintenance-free batteries with higher cold start amperage
- Service-friendly due to reduced variety of parts
Technology and engine
- Auxiliary fuel tank 120 l
- Trailer coupling
- High pressure connection kit for front mount attachments
- Charge pressure reduction (cold start aid)
- Stick control with power potentiometer for temporary increase of engine speed
- Hydraulic oil preheating
Cabin and comfort
- Seat belt with shoulder harness
- Parking heater
- Automatic climate control
- Premium sound package with Alpine subwoofer and amplifier
As a full-service provider, Kässbohrer not only supplies the technology, but also the appropriate training and software.
