600 polar W

Winch performance at a whole new level

Representative of a new generation. Pioneer and milestone. Dream machine. This is what can happen when a manufacturer develops a snow groomer in close cooperation with its customers. With the PistenBully 600 Polar W, we have jointly succeeded in setting new standards. In terms of power and performance. In efficiency, operation and comfort. The new PistenBully 600 Polar W raises winching on mountain to a whole new level.. And more environmentally friendly.

The PistenBully 600 Polar W is more than just a normal snow groomer. It stands not only for perfect slopes, but for sustainable and efficient slope management at the very highest level.

PistenBully 600 Polar winch: front with a lot of snow
The winch has an incredible power.
Dieter Damasko, driver ski center Mitterdorf, Germany

Showroom
PistenBully 600 Polar winch: side view
The chains of the PistenBully 600 Polar W for every application.
Tracks for every application

As flexible as a Swiss army knife, our undercarriage in combination with the chain can be adusted to all customer requirements and thus offers the perfect solution for every application, regardless of what is importantpushing, climbing, turning, or winching,

Combination equipment carrier

The combination equipment carrier is the "one for all" solution. Thanks to the SlopeTracer, it can follow the slope in parallel or slope contour mode. The Autotracer provides additional side-to-side support and perfect lateral tracking. Thus another must-have for the perfect slope.

The quick-change system of the PistenBully 600 Polar W.
Quick-mount system

Packed with stronger cylinders, load check valves and hydraulic pipe protection, the new quick-change system enables the highest attachment torques required for snowgun transport or pipe cutter tools. Of course, the unrestricted mobility is still maintained.

The special Polar shield of the PistenBully 600 Polar W.
AllWayBlade Polar

Wider, tallerr and stronger best describes the Polar blade. Designed for our most powerful PistenBully, it guarantees optimum grooming results and durability in the toughest applications or when transporting snow canons thanks to the standard mounting bracket.

The driver's cab of the PistenBully 600 Polar W.
Driver's cab

The driver is the center of attention. This guiding principle is realized in our cab with comfort, ergonomics and intuitive operation. Thanks to generous window glass, perfect arrangement and ideal LED illumination, visibility is exceptional, especially at night. The rear camera provides a clear view behind the winch.

The winch of the PistenBully 600 Polar W.
Winch

Thanks to the latest technology, the AutoWinch is perfectly matched to the vehicle. The combination of enormous pulling force, active steering and automatic control of winch pulling force ensures high production and safety on the slopes.  Completely automatic if desired.

 Cockpit PistenBully 600 Polar W.
The control unit of the cockpit of the PistenBully 600 Polar W.
Control unit

For a steady hand and safe handling in every driving situation: driver's seat, armrest and joystick are firmly connected. An ergonomic and comfortable unit. Individually adjustable to the driver. Enables fatigue-free operation, even when driving in rough terrain.

The high-quality interior trim in the cockpit of the PistenBully 600 Polar W.
Interior

High quality and easy to clean interior trim. New floor assembly. Both with innovative thermal insulation and significantly improved soundproofing, making the PistenBully 600 Polar W quieter than ever before. Optimized ventilation in the center console ensures a perfect interior climate - with comfort automatic air conditioning for the first time on request, plus plenty of space and freedom of movement.

 Joystick PistenBully 600 Polar W.
Joystick

Ergonomic and freely movable in all directions. For intuitive control. The joystick's four axes allow four simultaneous movements of the blade. And proportional control of the attachmentsalong with winch pulling force and active steering. All with just one hand.

 iTerminal PistenBully 600 Polar W.
iTerminal

10-inch display with touch control. Clear and easy to use. All active vehicle systems are highlighted in color. With quick navigation option via symbols. Completely prepared for SNOWsat.

Halblenkrad des PistenBully
Half-steering wheel

Precise steering: The semi-steering wheel is infinitely adjustable side-to-side and fits comfortably in the hand. The driver effortlessly steers the PistenBully and finds the most important functions directly in the steering.

Alternative Sticksteuerung
Alternative
Sticks

As an option to the steering wheel: Stick control for direct handling and steering. A thumb dial potentiometer regulates travel speed.

The compact engine of the PistenBully 600 Polar W.
The compact engine with simple design of the PistenBully 600 Polar W.
Compact motor

Compact engine with simple design. Fewer complex components and improved access. Thus clear, easy to maintain and less prone to malfunctions and errors.

Larger tank volume of the PistenBully 600 Polar W.
Larger tank volume

Significantly more power and torque than its predecessor despite lower fuel consumption. Long range due to larger tank volume for efficient and economical operation.

The diesel particulate filter of the PistenBully 600 Polar W.
Diesel particulate filter

Environmentally friendly pioneer: With the clean 6-cylinder engine with 520 hp including diesel particulate filter, the PistenBully 600 Polar W is the first snow groomer in the world to meet EU Stage V.

A freshly groomed slope.

Assistance systems

Assistenzsystem des PistenBully 600 Polar W: AutoTracer
AutoTracer

Rear implement carrier with intelligent, active steering assistance. Possible in both rigid position (fixed) and floating position (relieved). Automatic and autonomous steering in curves. Automatic countersteering on side slopes. For automatic support and relief of the driver!

Assistenzsystem des PistenBully 600 Polar W: SlopeTracer
SlopeTracer

Intelligent control of the combined equipment carrier. Can be used like a parallel tool carrier via software. Ensures perfect ground adaptation of the tiller in hilly terrain and automatically adjusts the milling depth. The patented SlopeTracer simplifies operation and enables very large movement radii.

Assistenzsystem des PistenBully 600 Polar W: AutoWinch
AutoWinch

Intelligent winch with automatic tension control. Can be switched on at the panel. Synchronizes travel speed and rope speed to each other. In the event of a deviation, for example due to slippage, the tractive force is increased – automatically.. Can be overridden manually if required. Protects the winch rope and aides the driver.

Technical data

Motor
TypeCummins X 12
Number of cylinders6
Displacement11,8 l / 11.800 cm³
Performance according to ECE382 kW / 520 PS
Max. torque2.375 Nm @ 1.200 U/min
Tank capacity300 l
Fuel consumptionfrom 19,5 l/h
Tank capacity DEF (AdBlue)38 l
Emission standardEU Stage V and EPA Tier 4F (USA)
Traction drive pump175 cm³
Traction drives125 cm³
Milling drive105 cm³
Winch
Tractive force stepless, automatic45 kN / 4,6 t
Technische Daten des PistenBully 600 und 600 Polar.
Motor
TypeCummins X 12
Number of cylinders6
Displacement11.8 l / 11,800 cc
Performance according to ECE512 hp
Max. torque2,250 Nm @ 1,200 rpm
Tank capacity79 gal
Fuel consumptionfrom 5.15 gal/h
Tank capacity DEF (AdBlue)10 gal
Emission standardEU Stage V and EPA Tier 4F (USA)
Traction drive pump175 cc
Traction drives125 cc
Milling drive105 cc
Winch
Tractive force stepless, automatic45 kN / 4.6 t

Winch 4.6+

360° unlimited. The new active winch with automatic winch pull control.

PistenBully 600 Winch: 4.6+ Winch
PistenBully 600 Polar winch in use
Winch features


AutoWinch
Rope speed precisely matched to travel speed via automatic tension control. Can be manually overridden if required. Protects the winch cable and aides the driver.

Active winch, maximum track stability
Enables automatic co-control of the winch boom.Optimum steering behavior is achieved even in difficult runway conditions and lateral traction loads.

Constant tractive force, new drive drum winch
The capstan drive ensures a constant high tractive force and rope speed, regardless of the remaining rope length on the reel. The advantage: More safety, especially at higher travel speeds.

Equipment

Transmission, Chassis & Wheels

  • Optimized transfer case with less noise and vibrations
  • Exclusively drawn axles for improved driving behavior
  • Shorter axles for better accessibility to the drive components
  • Reinforced rocker arm and wheel bearing due to larger tapered roller bearings
  • QuickAdjust for quick adjustment of the chassis via gear mechanism
  • Individual axle loads and spring characteristics for improved ride comfort (solo/winch)
  • More running smoothness and low pitching behavior thanks to damping of composite bushings
  • Magnum sprocket
  • Solid tires
  • Functional snow fenders to prevent snow ejection

Hydraulics and working hydraulics

  • Electro-hydraulic brake
  • New transfer gearbox angles the drivel pumps outward by 5
  • Optimized accessibility
  • 20% higher flow output than the predecessor
  • Optimized control for better efficiency
  • High pressure filter
  • Calibrated valves with identical response characteristics in all vehicles
  • Best performance values for speed and responsiveness
  • Individually adjustable valves
  • All functions can be controlled proportionally independently of each other
  • Common parts (e.g. proportional valves and solenoid coils)

Cabin

  • High-end sound system precisely matched to the vehicle
  • Rear camera color
  • DAB+ radio
  • Bluetooth hands-free kit
  • Connections: USB and audio in
  • Comfort driver's seat
  • Seatbelt with shoulder harness

Lighting

  • LED light package
  • LED SideFinder lights integrated in the support frame
  • LED TillerFlap lights
  • LED BladeFlap lights
  • Additional LED turn signals and tail lights integrated in the support frame

Electronics and batteries

  • Simple onboard diagnostics with error output in plain text
  • Automatic temperature compensation with cold start protection of components
  • Maintenance-free batteries with higher cold start current
  • Service-friendly due to reduced number of parts

Technology and engine

  • Auxiliary fuel tank (120 l)
  • Trailer hitch
  • High pressure connection kit for hydraulic front mount attachements
  • Charge pressure reduction (cold start aid)
  • Stick control with power potentiometer for temporary increase of motor speed
  • Hydraulic oil preheating

Cabin and comfort

  • Parking heater
  • Automatic air conditioning
  • Premium sound package with Alpine subwoofer and amplifier
Impressions
Everything from a single source

As a total provider, Kässbohrer not only supplies the technology, but also the appropriate training and software.
