600 polar W
Winch performance at a whole new level
Representative of a new generation. Pioneer and milestone. Dream machine. This is what can happen when a manufacturer develops a snow groomer in close cooperation with its customers. With the PistenBully 600 Polar W, we have jointly succeeded in setting new standards. In terms of power and performance. In efficiency, operation and comfort. The new PistenBully 600 Polar W raises winching on mountain to a whole new level.. And more environmentally friendly.
The PistenBully 600 Polar W is more than just a normal snow groomer. It stands not only for perfect slopes, but for sustainable and efficient slope management at the very highest level.
Highest power output in its class due to low dead weight, more power and higher torque. For better climbing ability and more thrust performance.
Joystick for intuitive control with just one hand. Clear iTerminal with simple operation. Driver's seat, joystick and armrest as ergonomic operating unit.
It was the first to meet the requirements of EU emissions stage V. With diesel particulate filter. For reduced exhaust emissions and low fuel consumption. Compact and easy to maintain.
The new active 4.6+ winch with AutoWinch (automatic winch pull control) is easy to operate even in difficult slope conditions.
“The winch has an incredible power.
As flexible as a Swiss army knife, our undercarriage in combination with the chain can be adusted to all customer requirements and thus offers the perfect solution for every application, regardless of what is importantpushing, climbing, turning, or winching,
The combination equipment carrier is the "one for all" solution. Thanks to the SlopeTracer, it can follow the slope in parallel or slope contour mode. The Autotracer provides additional side-to-side support and perfect lateral tracking. Thus another must-have for the perfect slope.
Packed with stronger cylinders, load check valves and hydraulic pipe protection, the new quick-change system enables the highest attachment torques required for snowgun transport or pipe cutter tools. Of course, the unrestricted mobility is still maintained.
Wider, tallerr and stronger best describes the Polar blade. Designed for our most powerful PistenBully, it guarantees optimum grooming results and durability in the toughest applications or when transporting snow canons thanks to the standard mounting bracket.
The driver is the center of attention. This guiding principle is realized in our cab with comfort, ergonomics and intuitive operation. Thanks to generous window glass, perfect arrangement and ideal LED illumination, visibility is exceptional, especially at night. The rear camera provides a clear view behind the winch.
Thanks to the latest technology, the AutoWinch is perfectly matched to the vehicle. The combination of enormous pulling force, active steering and automatic control of winch pulling force ensures high production and safety on the slopes. Completely automatic if desired.
For a steady hand and safe handling in every driving situation: driver's seat, armrest and joystick are firmly connected. An ergonomic and comfortable unit. Individually adjustable to the driver. Enables fatigue-free operation, even when driving in rough terrain.
High quality and easy to clean interior trim. New floor assembly. Both with innovative thermal insulation and significantly improved soundproofing, making the PistenBully 600 Polar W quieter than ever before. Optimized ventilation in the center console ensures a perfect interior climate - with comfort automatic air conditioning for the first time on request, plus plenty of space and freedom of movement.
Ergonomic and freely movable in all directions. For intuitive control. The joystick's four axes allow four simultaneous movements of the blade. And proportional control of the attachmentsalong with winch pulling force and active steering. All with just one hand.
10-inch display with touch control. Clear and easy to use. All active vehicle systems are highlighted in color. With quick navigation option via symbols. Completely prepared for SNOWsat.
Precise steering: The semi-steering wheel is infinitely adjustable side-to-side and fits comfortably in the hand. The driver effortlessly steers the PistenBully and finds the most important functions directly in the steering.
As an option to the steering wheel: Stick control for direct handling and steering. A thumb dial potentiometer regulates travel speed.
Compact engine with simple design. Fewer complex components and improved access. Thus clear, easy to maintain and less prone to malfunctions and errors.
Significantly more power and torque than its predecessor despite lower fuel consumption. Long range due to larger tank volume for efficient and economical operation.
Environmentally friendly pioneer: With the clean 6-cylinder engine with 520 hp including diesel particulate filter, the PistenBully 600 Polar W is the first snow groomer in the world to meet EU Stage V.
Rear implement carrier with intelligent, active steering assistance. Possible in both rigid position (fixed) and floating position (relieved). Automatic and autonomous steering in curves. Automatic countersteering on side slopes. For automatic support and relief of the driver!
Intelligent control of the combined equipment carrier. Can be used like a parallel tool carrier via software. Ensures perfect ground adaptation of the tiller in hilly terrain and automatically adjusts the milling depth. The patented SlopeTracer simplifies operation and enables very large movement radii.
Intelligent winch with automatic tension control. Can be switched on at the panel. Synchronizes travel speed and rope speed to each other. In the event of a deviation, for example due to slippage, the tractive force is increased – automatically.. Can be overridden manually if required. Protects the winch rope and aides the driver.
|Type||Cummins X 12|
|Number of cylinders||6|
|Displacement||11.8 l / 11,800 cm³|
|Performance according to ECE||382 kW / 520 PS|
|max. torque||2,375 Nm @ 1,200 U/min|
|Tank capacity||300 l|
|Fuel consumption||from 19.5 l/h|
|Tank capacity DEF (AdBlue)||38 l|
|Emission standard||EU Stage V and EPA Tier 4F (USA)|
|Traction drive pump||175 cm³|
|Traction drives||125 cm³|
|Milling drive||105 cm³|
|Tractive force stepless, automatic||45 kN / 4,6 t|
|Type||Cummins X 12|
|Number of cylinders||6|
|Displacement||11.8 l / 11,800 cc|
|Performance according to ECE||512 hp|
|max. torque||2,250 Nm @ 1,200 rpm|
|Tank capacity||79 gal|
|Fuel consumption||from 5.15 gal/h|
|Tank capacity DEF (AdBlue)||10 gal|
|Emission standard||EU Stage V and EPA Tier 4F (USA)|
|Traction drive pump||175 cc|
|Traction drives||125 cc|
|Milling drive||105 cc|
|Tractive force stepless, automatic||45 kN / 4.6 t|
360° unlimited. The new active winch with AutoWinch.
the current remaining rope length in the display
With automatic activation when reversing
to prevent operating errors
from castan pulleys to storage drum
to protect against possible damage to cable guide assemblies
with superior handling and rocking stability
during rope pull-out due to automatic pull-out
650 meter or 1,400 meter
remaining rope length on storage drum viewed on display screen
Rope speed precisely matched to travel speed via automatic tension control. Can be manually overridden if required. Protects the winch cable and aides the driver.
Active winch, maximum track stability
Enables automatic co-control of the winch boom.Optimum steering behavior is achieved even in difficult runway conditions and lateral traction loads.
Constant tractive force, new drive drum winch
The capstan drive ensures a constant high tractive force and rope speed, regardless of the remaining rope length on the reel. The advantage: More safety, especially at higher travel speeds.
Transmission, Chassis & Wheels
- Optimized transfer case with less noise and vibrations
- Exclusively drawn axles for improved driving behavior
- Shorter axles for better accessibility to the drive components
- Reinforced rocker arm and wheel bearing due to larger tapered roller bearings
- QuickAdjust for quick adjustment of the chassis via gear mechanism
- Individual axle loads and spring characteristics for improved ride comfort (solo/winch)
- More running smoothness and low pitching behavior thanks to damping of composite bushings
- Magnum sprocket
- Solid tires
- Functional snow fenders to prevent snow ejection
Hydraulics and working hydraulics
- Electro-hydraulic brake
- New transfer gearbox angles the drivel pumps outward by 5
- Optimized accessibility
- 20% higher flow output than the predecessor
- Optimized control for better efficiency
- High pressure filter
- Calibrated valves with identical response characteristics in all vehicles
- Best performance values for speed and responsiveness
- Individually adjustable valves
- All functions can be controlled proportionally independently of each other
- Common parts (e.g. proportional valves and solenoid coils)
- High-end sound system precisely matched to the vehicle
- Rear camera color
- DAB+ radio
- Bluetooth hands-free kit
- Connections: USB and audio in
- Comfort driver's seat
- Seatbelt with shoulder harness
- LED light package
- LED SideFinder lights integrated in the support frame
- LED TillerFlap lights
- LED BladeFlap lights
- Additional LED turn signals and tail lights integrated in the support frame
Electronics and batteries
- Simple onboard diagnostics with error output in plain text
- Automatic temperature compensation with cold start protection of components
- Maintenance-free batteries with higher cold start current
- Service-friendly due to reduced number of parts
Technology and engine
- Auxiliary fuel tank (120 l)
- Trailer hitch
- High pressure connection kit for hydraulic front mount attachements
- Charge pressure reduction (cold start aid)
- Stick control with power potentiometer for temporary increase of motor speed
- Hydraulic oil preheating
Cabin and comfort
- Parking heater
- Automatic air conditioning
- Premium sound package with Alpine subwoofer and amplifier
As a total provider, Kässbohrer not only supplies the technology, but also the appropriate training and software.
